Overall Length | 7005 mm | |
Overall Width | 2050 mm | |
Overall Height | 2640 ,2760 mm | |
Interior Height | 1820 mm | |
Wheelbase | 3935 mm | |
Front Overhang | 1150 mm | |
Rear Overhang | 1920 mm | |
First Step Height | 400 mm | |
Gross Vehicle Weight | 5900 kg | |
Seats Capacity | 44860 | |
Rear Luggage Compartment Volume* | 0.25 m3 | |
Engine Model | YC4FA130-30 | |
Engine Type | in-line,water-cooled, 4 cylinders, | |
| turbocharged, electronic control, direct injection | Safety & Performance |
Position/Fuel | Front/diesel | Standard |
Max Output | 95 kw | ABS (Antilock Braking System) |
Max Torque | 340Nm/rpm | GPS System, vehicle travelling data recorder |
Displacement | 2982mL | Speed-limiting device (100km/h top ) |
Emission Standard | national standard III | Safety belt equipped with every seat |
Chassis | | Heating system |
Chassis Model | EQ6680KS3T | Dongfeng Pannico top-mounted A/C 12KW(10500cal/h) |
Gear box | DF5S410 | Antiskid floor, digital clock |
Clutch | Single plate, dry friction, diaphragm spring /Φ325mm | Interior rearview mirror, sun visor for the driver |
Front Axle | Jiang Lin (2.25T) Disc brake | Side window curtain, rear window curtain, tyres decorate cover |
Rear Axles | Jiang Lin (4T), i=4.875 | 4 safety hammer, 2kg Fire Extinguisher |
Suspension | Leaf spring front 3 rear 4 | Optional |
Steering | Power steering | Nan Feng fuel heater YJ-Q11.6R |
Brakes | Dual circuit liquid brake | LG antiskid floor, 4kg Fire Extinguisher |
Fuel Tank | 300L | 7-inch color screen reversing rearview monitoring system |
Tyres | 7.00R16 | Entertainment Systems & Digital Amenities |
Parking Brake | central drum regulation brake | Standard |
Battery/Generator | 6-QA-180, 12V/150A | MP3 radio system |
Others | Adjustment arm; ABS; air dryer; copper water tank; | Digital clock |
| engine intake air preheater | Adjustable armrest, 2+1 layout |
Body | | Driver door, middle electric folding door |
Body Type | Stainless steel frame, | New front and rear combination lamp |
| punch forming of front mold and rear mold | Front/rear fog lamp, side steering lamp, high mount stop lamp |
Interior Trimming | Coaster luxurious interior trimming; | Optional |
| | MP4/MP5 video system |
Side Window | Fully sealed, integrated splice windows in green color; | 15-inch color LCD |
windscreen | Front : laminated glass; Rear : toughened glass | U flash disc, SD card |
Defroster | Defroster with changeable power 24V,130W | Folding side window curtains,rolling sunshade curtains |
Windscreen Wiper | Front: double arms type; Rear: single arm type | Monitoring system |
