    Tipper Truck Dump Truck from Shacman 40 tons 8x4 with and Wheel Rim 13.00/2.0-25

    Ask Lasest Price
    Brand Name : Shacman
    Price : $25,000.00/units 1-2 units
    • Product Details
    • Company Profile

    Tipper Truck Dump Truck from Shacman 40 tons 8x4 with and Wheel Rim 13.00/2.0-25

    Product Video
    Products Description
    Shacman 380 HP 8X4 Used Dump Truck

    Truck Fatures:

    1) New tipper box

    2) New tyres

    3) New cab interior

    4) Better price-performance Ratio

    5) 380 HP big power

    6) Better performance and high efficiency

    7) MAN Technology Axles with better duration
    Tipper Truck Dump Truck from Shacman 40 tons 8x4 with and Wheel Rim 13.00/2.0-25
    Tipper Truck Dump Truck from Shacman 40 tons 8x4 with and Wheel Rim 13.00/2.0-25
    Tipper Truck Dump Truck from Shacman 40 tons 8x4 with and Wheel Rim 13.00/2.0-25
    Tipper Truck Dump Truck from Shacman 40 tons 8x4 with and Wheel Rim 13.00/2.0-25
    Tipper Truck Dump Truck from Shacman 40 tons 8x4 with and Wheel Rim 13.00/2.0-25
    Tipper Truck Dump Truck from Shacman 40 tons 8x4 with and Wheel Rim 13.00/2.0-25
    Product Paramenters
    Item
    Data
    Item
    Data
    Max.Design Weight（kg）
    108000
    Overall Dimension（LxWxH）（mm）
    9770x4230x4560
    Unladen/Laden Max.Speed（km/h)
    48/41
    Unladen/Laden Max.Gradeability（°）
    36.7
    Struck Capacity (flat/ heaped)m³
    38/44
    Min.Turning Diameter(m)
    ≤24
    Curb Weight（kg）
    39000
    Payload(kg)
    70000
    Wheel Tread（mm）
    Front Axle：3120；Middle-Rear Axle：2910
    Wheelbase（mm）
    3910（Front-Middle）1800（Middle-Rear）
    Approaching Angle(°）
    31
    Departure Angle（°）
    60
    Ground Clearance（mm）
    ≥466 /406
    Number of Axles
    3
    Make
    Weichai WP13G530E310
    Number of Cylinder
    6
    Type
    Line, Direct Injection, Water-cooling, Inter-cooling, Electric-controlled
    Bore/Stroke（mm）
    127/165
    Rated Power(kW)
    390
    Min. Fuel Consumption（g/kW.h)
    195.9
    Rated Speed(r/min)
    2100
    Max. Torque（N.m)
    2300
    Emission load (ml)
    12540
    Emission Standard
    StageIII GB20891-2014
    Auto Gearbox
    FC6A250PRT
    Type
    planetary
    Speed Ratio
    1st
    4.4
    2nd
    2.33
    3rd
    1.53
    4th
    1.00
    5th
    0.72
    6th
    0.61
    R1
    3.97
    Front Axle
    Steering Axle
    Welded Axle Housing
    Middle-Rear Axle
    Main Reduction Ratio
    4.11
    Wheel Edge Reduction Ratio
    4.952
    Total Reduction Ratio
    20.357
    Wheel
    Rim
    13.00/2.0-25
    Tyre
    18.00R25
    Tyre Pressure（MPa）
    0.8
    Suspension System
    Front Suspension
    Leaf spring + double-acting cylinder shock absorber
    Rear Suspension
    Spring + Rubber balance suspension
